Device Type | IP-camera |
Connection type | wired |
Installation location | inside, outside |
Matrix resolution | 4 Mpx |
Wi-Fi support | no |
Video standard | IP |
Type of instalation | wall, ceiling, overhead |
Form factor | dome |
Intended for use | home, house, office, store, warehouse, production, garage |
Matrix type | 1/3” progressive CMOS |
Recording speed | Main Stream 4 МP - 1 - 25 fps, 3 МP - 1 - 25 fps, 1080р - 1 - 25 fps, 720р - 1 - 25 fps, Sub Stream D1 - 1 - 25 fps, VGA - 1 - 25 fps, CIF - 1 - 25 fps |
Camera motion sensor | program |
Lens type | fixed |
Focal length | 3.6 mm |
Viewing angle | 81° |
Optical zoom | 1x |
Digital zoom | 1x |
Light sensitivity | 0.004 Lx/F1.0 (Color), 0 Lx with IR |
Light distance | 30 m |
Type of illumination | white light |
Day-night mode | yes, ICR filter |
Memory card slot | yes |
Built-in microphone | yes |
Built-in speaker | no |
Video output | 1xRJ45 |
Audio inputs | no |
Audio outputs | no |
Network output | 1xRJ45 |
Network Interface | 1 RJ-45 (10/100Base-T), IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, 802.1x, Bonjour |
Type of memory cards | microSD up to 256GB |
PoE support | yes |
PoE type | 802.3af |
Video compression | H.264, H.264+, H.265, MJPEG |
Alarm Inputs-Outputs | no |
Alarm inputs | no |
Alarm outputs | no |
Modes | 3D DNR / BLC / HLC / WDR / ROI |
Streaming | 2 streams |
Built-in lightning protection | no |
Additional functions of camera | cloud storage, region of interest (ROI) |
Moisture and dust protection | IP67 |
Vandal protection | no |
Browsers | Chrome, Firefox, Safari, Edge, Opera |
OS support | Windows, MAC OS, IOS, Android |
Powered by batteries / rechargeable batteries | no |
Integration with Ajax system | yes |
Mobile app | DMSS |
Special features | crossing the line, invading the area |
Compatibility | with Dahua DVRs |
Consumption | 7.4 W |
Operating voltage | 12V DC, PoE |
Dimensions (WхHхD) | Ø 110х101 mm |
Body color | white |
Body material | metal |
Weight | 365 g |
Temperature range | -40...+60°C |
Producing country | China |
Device class | middle |
